Everything in detail

Hilux SR5 specifications

Highlights

Smartphone Integration: Expand your digital ecosystem

Seamless smartphone integration ensures you and your Hilux stay connected. With this built-in function, drivers can seamlessly access apps, calls, and music through the vehicle’s multimedia system.

Smart Entry & Start System: For a seamless start

Set off with ease from the get-go, thanks to Toyota's Smart Entry & Start System. All you need to do is to have the key on you; the function will unlock the driver's door, and start the engine at the push of a button.

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior length (mm): 5325 mm
Number Of Doors: 4
Exterior height (mm): 1865 mm
Exterior width (mm): 1855 mm
Wheelbase (mm): 3085 mm
Front Tread (mm): 1540 mm
Rear Tread (mm): 1550 mm
Front overhang (mm): 985 mm
Rear overhang (mm): 1255 mm

Interior dimensions

Number Of Seats: 5 seats

Load Volume

Deck Length (mm): 1555 mm
Deck Width (mm): 1540 mm

Engine

Drive with pure emotion, powered by a high-performance engine that helps you take on any journey with confidence.

Environmental Performance

CO2 Combined WLTP (g/km): 247 g/km
Euro Class: Euro 6 AR
Exhaust Emissions EC Regulations (Update): 2018/1832AR
Fuel Combined WLTP (l/100 km): 9.4 litres/100 km
Recommended fuel grade: 48 OR MORE (CETANE)
Fuel tank capacity (litres): 80 l
Nitrogen Oxides, NOx (mg/km): 46.8 mg/km
Sound Level Drive By (dB(A)): 71.0 dB(A)
Fuel Tank Capacity (l): 80 l

Performance

Maximum Speed (km/h): 175 km/h
0-100 km/h (secs): 10.13 seconds

Engine

Number Of Cylinders: 4 Cylinder, In Line
Valve mechanism: DOHC 16-valve
Fuel system: Fuel injection
Displacement (cc): 2755 ccm
Bore x Stroke (mm x mm): 92 x 103.6 mm
Compression Ratio: 15.6:1
Maximum power output (kW/rpm): 150 kW@rpm
Maximum output (bhp): 204 bhp
Maximum torque (Nm/rpm): 420 Nm

Transmission

Drive: 4WD
Transmission Type: Manual

Suspension

Front: DOUBLE WISHBONE
Rear: Leaf spring rigid axle

Brakes

Front: Ventilated disc 4-cylinder
Rear: Drum

Weights & towing capacity

Kerb Weight (kg): 2120-2320 kg
Gross vehicle weight (kg): 3210 kg
Towing Capacity With Brakes (kg): 3500 kg
Payload (kg): 1015 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

Spare wheel carrier under body
Turning signal integrated in door mirrors
Daytime running lights (bulb type)
Headlamp cleaners
Front fog lamps (LED type)
Brake Assist (BA)
Rear-view camera
Anti-lock Braking System (ABS)
Emergency Brake-light Signal (EBS)
Rear combination lamps (bulb type)
Road Sign Assist
Downhill Assist Control (DAC)
Hill-start Assist Control (HAC)
Vehicle Stability Control (VSC)
Immobiliser
High-mounted stop lamp (LED type)
LED rear brake lights
Traction Control (TRC)
Trailer Sway Control (TSC)
Turning signal (bulb type)
Pre-Collision System with Pedestrian and Cyclist Detection
Lane Departure Alert with brake-induced Steering
Intelligent Adaptive Cruise Control
Rear fog lamps
Multi-reflector halogen headlamps (4 bulb)
eCall emergency call system
Tyre Pressure Warning System (TPWS)
Automatic High Beam (AHB)
Lane Trace Assist (LTA)
Toyota Safety Sense

Supplemental Restraint System (SRS) airbags
ISOFIX seat fixing
Rear seat belt reminder
Front seat belt reminder
Rear headrests (3)
Pre-tensioners and force limiters
Front passenger airbag detector
Adjustable front driver seat belt extender
Adjustable rear headrests
Handbrake
Rear middle 3-point seat belt
Front passenger airbag on/off-switch

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

Chrome surround on upper front grille
Body-coloured front bumper
Black front spoiler
Chrome rear bumper
Chrome tailgate release handle
Chrome door mirrors
Chrome door handles
Chrome door belt moulding
Privacy glass on rear windows
Black rear pillar design
Black side steps
Wide front bumper
Black painted upper front grill
Black painted lower front grille
Shark-fin antenna
Black extended surrounds on front fog lamps

Black upper dashboard
4-spoke leather steering wheel
Black centre console
Black insert on centre console
Chrome insert on centre air vents
Silver side air vent surrounds
Chrome insert on side air vents
Leather gear shift knob
Silver surround on gear shift console
Chrome button on handbrake
Leather-like armrest
Silver insert on centre console box
Fabric front door armrests
Black front door armrests
Chrome interior door handles
Rear armrest
Open tray on passenger dashboard
Chrome surround on air conditioning buttons
Silver and chrome insert on dashboard
Silver and chrome deco line on upper dashboard
Urethane handbrake
Silver insert on gear shift knob
Black side air vents

Performance

From road-ready handling to efficient acceleration – discover what makes the Toyota driving performance so special.

Front spoiler
Steering Angle Display
Rear differential lock
Comfort suspension
Pitch & Bounce control
Double wishbone front suspension
Leaf spring rear suspension

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Full spare steel wheel
All-terrain tyres

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Rear step on bumper
Follow-me-home headlights
Dusk sensor
Headlight cut-off reminder
Tailgate release with key
Tailgate
Power-adjustable door mirrors
Heated door mirrors
Power-retractable door mirrors
Smart Entry & Start System
Side steps
Remote door lock
Smartphone remote door lock
Smartphone remote hazard lights system

Push-button start
Manual tilt steering wheel
Manual telescopic steering wheel
Analogue speedometer
Analogue tachometer
Power steering
Variable Flow Control (VFC) power steering
Manual day/night rear-view mirror
Rear-view camera display in audio screen
Static guide lines on rear-view camera display
Pollen air filter
Clean air filter
Manually height-adjustable driver seat
Heated driver & front passenger seats
Rear door armrests
60:40 split tip-up rear bench
Rear passenger footwell heating
Front power windows
Rear power windows
Power passenger window lock
Fixed rear window
Shade band on windshield
Front wiper de-icer
Washer fluid level warning
Rear window defogger
Time adjustment on intermittent wiper
Front room lamp
Centre room lamp
Rear passenger room lamp
Illuminated entry system
Mirror on passenger sun visor
Front 12V power outlet (2)
Power door lock
Child safety door lock
Key reminder warning
Coloured TFT information displays
4.2" screen for information displays
ECO-driving Indicator
Audio switches on steering wheel
Information display switches on steering wheel
Telephone switch on steering wheel
Voice recognition switch on steering wheel
Adaptive Cruise Control switch on steering wheel
Lane Departure Alert switch on steering wheel
Front overhead assist grips
Rear overhead assist grips
Front pillar assist grips
Centre pillar assist grips
Driver & front passenger personal lamps
Multimedia switches on steering wheel
Auto up & down function on 2nd row power windows
Auto up & down function on front power windows
Anti-jam protection on front power windows
Dual-zone climate control
Front 220V power outlet
Intermittent wiper

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

Bluetooth® hands-free system
Digital Audio Broadcast (DAB)
6 speakers
8" multimedia display
Toyota Touch® 2 multimedia system
USB connector
Microphone on front personal lamp
Smartphone Integration with Apple CarPlay/Android Auto
MyT Connected Services

Storage

This fantastic interior space offers plenty of room for all ‒ including ample legroom to comfortably stretch your legs, and a spacious boot to fit everything you’ll need.

Cargo deck
